60# 70# SWRH 72A Copper Coated Steel Wire bead tyres FOR PE pipe

China 60# 70# SWRH 72A Copper Coated Steel Wire bead tyres FOR PE pipe supplier
60# 70# SWRH 72A Copper Coated Steel Wire bead tyres FOR PE pipe supplier 60# 70# SWRH 72A Copper Coated Steel Wire bead tyres FOR PE pipe supplier 60# 70# SWRH 72A Copper Coated Steel Wire bead tyres FOR PE pipe supplier 60# 70# SWRH 72A Copper Coated Steel Wire bead tyres FOR PE pipe supplier

Large Image :  60# 70# SWRH 72A Copper Coated Steel Wire bead tyres FOR PE pipe

Product Details:

Place of Origin: China
Brand Name: GANGDA
Model Number: GD- 01-12

Payment & Shipping Terms:

Minimum Order Quantity: 1 Tonne
Packaging Details: 400 kgs with Spooless cores Z-2 Packs, 2 or 3 Coills in one Pallet, 24 Pallets per 20" Container, 20 to 25 tonners per 20" Container
Delivery Time: 20 days
Supply Ability: 1000 tonners per month
Contact Now
Detailed Product Description
Application: Air Duct, PE Pipe Finshes: Copper Plated
Steel Grade: High Carbon Steel Packaging: 400kgs Coil Z2 With Paper Core
Standard: GB14450-2003 Wire Rod: 60# 70# SWRH72A

Copper Plated Tyre Bead Wire Diameter  0.60 to 3.0mm  Tensile Strength 1500 to 2300 Mpa  Z2 Packs



Specifications



1.Diameter:  a. 0.60mm 0.70mm 0.78/0.80mm 0.89/0.90mm 1.00mm                                                                              1.10mm1.20mm 1.26mm1.30mm
                      b. 1.50mm 1.65mm 1.80mm 2.00mm 2.20mm 2.30mm
                      c.  2.80mm 3.00mm 3.10mm 3.20mm 3.30mm 3.50mm
                      Diameter Tolerance: +/- 0.02mm or +/-0.03mm
2. Finish: Copper coating
3. Weight of bronze coating: 0.30 -1.35 g/kg
4. Tensile Strength:  a. 1750 – 2300 Mpa
                                   b. 1500 – 1900 Mpa
                                   c.  as per client's request
5. Steel Grade: High Carbon Steel  C1065  C1070  C1072  C1080
6. Package: 400kgs+/-20kgs with spooless cores Z-2 Packs, 2 or 3 coils in one pallet.
                    ID: 355mm Min.
                    D: 720mm Max.
                    Wire reel Width: 280mm
7. Standard: GB14450-2004 or as per client’s specification




Description:



Bronze Coated Bead Wire is manufactured from quality high carbon wire rods, with superior surface coating and are used for the reinforcement of all sorts of reliable hose, duct and pipe.




Applications:



Armoured hoses
Flexible ducting
Hose reinforcing
Pipe




Competitive Advantage:



Excellent surface coating
Trouble-free forming
Trouble-free pay off
