Product Details:
Payment & Shipping Terms:
|
| Application: | For Tyre Bead Wire Manufacture | Size: | 1.20MM |
|---|---|---|---|
| T/S: | HT 2000 MPa Min. | Steel Grade: | CADA 82A |
| Pack: | 400kgs Z-2 Pack | Surface: | Bright |
| Process: | Cold Drawn | ||
| High Light: | tire bead wire,spring steel wire |
||
Bright High Carbon Spring Wire for Tire Bead Wire
Wire Diameter: 1.20mm
Tensile Strength: HT 2000 -2400 N/MM2
Surface: Without coating
Manufacture of Tire Bead Wire
1.Steel rod carbon content: 0.80 %
2. Physical properties Unit TARGET Min. Max. METHOD
|
Diameter mm |
1.20 1.18 1.22 |
|
|
Tensile strength MPa |
2122 2000 |
ISO 6892-1 |
|
Breaking Force N |
2400 2290 |
ISO 6892-1 |
|
Number of bends r=2.5 - |
- - - |
- |
|
Torsions @ break (100*d) - |
- 32 - |
ISO 7800 |
3.Straight Unit TARGET Min. Max. METHOD
|
Cast of wire mm |
- 360 - |
|
|
Helix mm |
0 - 100 |
|
4. Other Parameters Unit TARGET Min. Max. METHOD
|
Number of welds on reel |
- - 1 |
|
|
Weld strength N |
- 600 - |
ISO 6892-1 |
|
Diameter at weld mm |
- - 0.930 |
|
|
Weight of coil kg |
450 400 460 |
|
|
Width of coil mm |
280 - 295 |
|
