Product Details:
Payment & Shipping Terms:
|
Standard: | ASTM A 227/ A 227M - 1999 | Steel Garde: | Non - Alloy Steel |
---|---|---|---|
Surface: | Bright / Uncoated | Finishes: | Phosphate |
Size Range: | 0.50mm - 4.00mm | Application: | Mechanical Spring |
High Light: | carbon steel wire,industrial steel wire |
GUAHGHUA - a leading manufacturer and exporter of non alloy steel wire. every year we export great many steel wire products to America, EU, Australia, which are producted according to ASTN A227/ A 227 M.
1. Surface: Without coating
2. Standard: ASTM A 227/ A 227 M - 1999
3. Diameter and Tensile Strength
Tensile Requirements, SL Units
Diameter mm |
Class I |
Class II |
||
Tensile Strength, MPa |
Tensile Strength, MPa |
|||
min |
max |
min |
max |
|
0.50 |
1960 |
2240 |
2240 |
2520 |
0.55 |
1940 |
2220 |
2220 |
2500 |
0.60 |
1920 |
2200 |
2200 |
2480 |
0.70 |
1900 |
2180 |
2180 |
2460 |
0.80 |
1870 |
2140 |
2140 |
2410 |
0.90 |
1830 |
2100 |
2100 |
2370 |
1.00 |
1800 |
2070 |
2070 |
2340 |
1.10 |
1770 |
2040 |
2040 |
2310 |
1.20 |
1740 |
2000 |
2000 |
2260 |
1.40 |
1720 |
1980 |
1980 |
2240 |
1.60 |
1670 |
1930 |
1930 |
2180 |
1.80 |
1640 |
1880 |
1880 |
2120 |
2.00 |
1600 |
1840 |
1840 |
2080 |
2.20 |
1580 |
1810 |
1810 |
2040 |
2.20 |
1550 |
1780 |
1780 |
2010 |
2.50 |
1510 |
1730 |
1730 |
1960 |
2.80 |
1480 |
1700 |
1700 |
1920 |
3.00 |
1460 |
1680 |
1680 |
1900 |
3.50 |
1420 |
1630 |
1630 |
1840 |
4.00 |
1380 |
1590 |
1590 |
1800 |
4. Raw Material: Quality carbon steel wire rod C1045 - C1085
Chemical Requirements
Element |
Composition, % |
Carbon |
0.45 – 0.85 |
Manganese |
0.30 – 1.30 |
Phosphorus, max |
0.040 |
Sulfur, max |
0.050 |
Silicon |
0.15 – 0.35 |
4. Cast : As per client’s request
Spring and mechanical componnent manufacture
